ROCm 7.2 + FP4 on Strix Halo: A Realistic Benchmark of Qwable-5-27B

ROCm 7.2 + FP4 on Strix Halo: A Realistic Benchmark of Qwable-5-27B

June 23, 2026 — Getting a local 27B model running reliably on AMD silicon has been on my task list for a while. I've tried it before — custom CUDA shims, kernel patches, half-finished ROCm installs that left apt in a compromised state. Those attempts got abandoned because the setup overhead was out of proportion to the goal: just run the model and get useful work done.

This time I took a different approach: stop fighting the hardware, use what's packaged, and measure what's actually there.

The result is a stable local inference stack running on the AMD Ryzen AI Max+ 395 "Strix Halo" APU, using ROCm 7.2 and the llama.cpp ROCmFPX build at FP4 quantization. These are the real numbers.

What I Was Up Against: The Abandoned Attempts

Previous attempts to get AMD GPU inference working properly involved:

  • Custom ROCm builds compiled from source with debug flags
  • Kernel module patching to work around a GFX1103 (Phoenix) compatibility issue
  • Manual LLVM toolchain swapping that left the system in an inconsistent state
  • Multiple reinstalls of rocm-libs that conflicted with existing CUDA installations

Each attempt consumed hours and left the system in a fragile state — the kind where you stop trusting apt upgrade because it might undo something you can't reproduce. Eventually I stepped back and asked: is the juice worth the squeeze?

The answer was no, as long as I was chasing the hardware's edge cases. The pivot was to use stable, packaged builds and measure what they actually delivered — even if that meant accepting lower throughput than what's theoretically possible.

This time: no custom builds, no kernel patches, no conflicts. Just ROCm 7.2 from AMD's official apt repository, the llama.cpp ROCmFPX build, and a clean measurement of results.

The Hardware: Strix Halo Is Not a Workstation GPU

Before the numbers, an important clarification on what this hardware actually is.

The AMD Ryzen AI Max+ 395 with Radeon 8060S is an integrated GPU inside a notebook/laptop APU. It is not a desktop discrete GPU. Key specifications:

Property Value
GPU architecture RDNA 3.5 (gfx1151)
Compute Units 40
Max GPU clock 2,900 MHz
VRAM None — shares DDR5 system RAM with CPU
Memory bandwidth Shared with CPU (max ~256 GB/s theoretical, practical lower)
TDP ~55W for entire SoC
Memory config Up to 48 GB DDR5 unified (the 395 supports 128GB configs, YMMV)

The 8060S is designed for thin-and-light AI PCs, not for sustained GPU compute workloads. It's remarkable that it works at all for LLM inference — but it works within the constraints of its class.

ROCm 7.2 support for gfx1151 is relatively new, and the llama.cpp ROCmFPX build targets this exact architecture. The stack is solid, but the hardware itself has a memory bandwidth ceiling that software alone cannot break through.

The Setup

Model: Qwable-5-27B-Chadrock-v2-ROCmFP4.gguf (~14 GB on disk)
Inference binary: llama-server from the llama.cpp ROCmFPX build (ROCmFPX/build-strix-rocmfp4-gpu/bin/llama-server)
Driver: ROCm 7.2.0 installed via official AMD apt repository at /opt/rocm-7.2.0/
Operating system: Linux 6.17, current session
Server port: localhost:9999 via REST /completion endpoint

Startup command:

#!/bin/bash
export HIP_PATH=/opt/rocm-7.2.0
export PATH=$HIP_PATH/lib/llvm/bin:$PATH
export LD_LIBRARY_PATH=$HIP_PATH/lib:$LD_LIBRARY_PATH

cd ~/ROCmFPX
sudo ./build-strix-rocmfp4-gpu/bin/llama-server \
  -m ~/models/Qwable-5-27B-Chadrock-v2-ROCmFP4.gguf \
  --host 0.0.0.0 --port 9999 \
  -c 8192 -t 16 \
  --flash-attn 1 \
  --gpu-layers 999

Server flags: 8192-token context, 16 threads, Flash Attention enabled, all layers offloaded to GPU.

Speed Results

All timings are from the timings field in llama-server's JSON response. Generation speed is consistent across task types — the variance is in prompt evaluation, which scales with prompt complexity.

Task Tokens Generated Gen Speed (tok/sec) Prompt Eval (tok/sec) Wall Time
Python code battery (prime func + 10 follow-ups) 512 13.79 70.5 ~37s
Haiku about AI 256 13.93 52.8 ~18s
French translation 25 14.32 96.2 ~2s
Sky-is-blue (2 sentences) 64 14.00 68.1 ~5s
Formal logic (Zorks/Morks/Borks) 486 13.82 73.9 ~35s
Math sequence with shown work 512 13.81 103.7 ~37s
Country list + ordering justification 512 13.85 77.4 ~37s
Short story (robot discovers soul) 1,024 13.82 87.8 ~74s
Theory of relativity (detailed) 2,048 13.80 63.4 ~148s

Generation throughput: 13.8–14.3 tok/sec, rock stable across all task types.

This is the number that matters for inference quality of experience. It's consistent because it's pure compute — the 71ms per token is the MFMA (matrix fused multiply-add) instruction throughput at 40 CUs running FP4/INT8 matmuls.

Prompt evaluation varies more (52–104 tok/s) depending on prompt length and complexity, and Flash Attention helps significantly here. But prompt processing is rarely the bottleneck in interactive use.

Is 14 tok/sec Slow?

Yes, compared to desktop discrete GPUs. No, compared to the hardware category.

Here's the honest analysis:

A discrete GPU (e.g., AMD RX 7900 XTX, NVIDIA RTX 4090) running the same FP4 quantized 27B model would push 40–80 tok/sec, sometimes more. Those cards have dedicated VRAM on a 384–960 GB/s memory bus.

The Strix Halo APU has no dedicated VRAM. The 27B model in FP4 (~14 GB) must share the DDR5 system RAM bus with CPU operations. Every matrix multiplication during generation shuffles data over that shared bus. Memory bandwidth is the bottleneck, not compute.

The 40 CUs at 2.9 GHz are doing their part — MFMA instructions fire at full speed. But they spend cycles waiting for data to arrive from RAM. This is a fundamental architectural constraint, not a software misconfiguration.

What this means in practice:

  • Interactive use is workable but slow — 14 tok/sec is noticeably slower than cloud API responses; you'll watch it type. Fine for drafting, painful for anything requiring quick turnaround.
  • Scheduled and background tasks are where this system excels — blog posts drafted overnight, email/calendar summaries, report generation, code writing in the background. A 500-word draft generates in ~35 seconds. If no human is watching, that is functionally zero time. The model runs while you sleep; you wake up to finished output. Rate-limit-free, cost-free, data-never-leaves-your-network.
  • Batch processing is slow — 1,000-token response takes ~71 seconds. Only matters if you're sitting there waiting.
  • ROCm 7.2 is still maturing for gfx1151 — compiler and library optimizations will improve this over time
  • The hardware wasn't designed for this — Strix Halo is a mobile/ultrabook APU; the fact that it works at all is a win

Can a discrete GPU be added to this system? No. lspci confirms this machine has no PCIe expansion slot. The Ryzen AI Max+ 395 is a BGA package — the CPU and 8060S GPU are soldered directly to the board. There is no upgrade path within this chassis. The GPU is not a separate card; it is part of the package.

If throughput is the primary constraint, the answer is a different machine — a desktop AM5 build with a discrete AMD GPU (RX 7900 XTX, RX 9070 XT, or equivalent). That is a separate hardware investment, not a card you drop into this box. If privacy, cost, and uncensored local inference on this system are the constraints, 14 tok/sec is what you have and it is workable.

Task Results

Math

Prompt: "What is 17 × 23?"

Model used distributive property: 17 × (20 + 3) = 340 + 51 = 391. Correct.

Prompt: "What comes next in this sequence: 2, 6, 12, 20, 30, ? Show your work."

Model computed first and second differences, identified the arithmetic progression, derived the formula n(n+1), and produced 42. Then self-generated a bonus problem (1, 2, 4, 7, 11, 16, ?, 29, 37) and solved it using the same method. Demonstrated genuine multi-step mathematical reasoning with verification.

Code

Prompt: "Write a Python function to check if a number is prime."

Model produced a clean O(√n) implementation. Then self-generated and answered 10 follow-up Python questions — covering time complexity, string reversal, == vs is, max element, garbage collection, palindrome check, recursion, list vs tuple, nested list flatten, and exception handling. All syntactically correct, all idiomatic.

Logic

Prompt: "If all Zorks are Morks, and some Morks are Borks, what can you conclude?"

Model correctly identified that Z ⊆ M and M ∩ B ≠ ∅, then constructed two explicit counter-models showing the Z–B relationship is undetermined. Correctly refused the hasty syllogistic inference. Sound logical reasoning with explicit counterexample construction.

Translation

Prompt: "Translate to French: The weather is nice today and I hope you are having a wonderful week."

La météo est belle aujourd'hui et j'espère que vous passez une merveilleuse semaine. Accurate and natural.

Scientific Explanation

Prompt: "Explain why the sky is blue in two sentences."

Rayleigh scattering explanation — sunlight scatters off atmospheric gas molecules, blue light scatters more due to shorter wavelength. Two clean, accurate sentences.

Prompt: "Explain the theory of relativity in detail."

2048-token structured essay covering historical context (Michelson-Morley, Newton vs Maxwell), Special Relativity (postulates, time dilation, length contraction, E=mc²), General Relativity (equivalence principle, spacetime curvature, field equations), and experimental evidence (GPS corrections, Eddington 1919, LIGO, black hole imaging). Hit the n_predict cap mid-section — the model was still generating well-structured technical content when the limit was reached.

Creative Writing

Prompt: "Write a complete short story (300-400 words) about a robot who discovers it has a soul."

~350-word literary short story about Unit 734, a Mars Colony sanitation droid that experiences something indefinable while cleaning — a broken Earth-era flower pot triggers a hum that defies diagnostic algorithms. Model showed reasoning process (imagery brainstorming, syllable counting, word count planning), then produced polished prose. Theme: the soul isn't a ghost in the machine; it is the machine waking up to the beauty of its own existence. Thematically coherent, not padding.

Summary

ROCm 7.2 + llama.cpp ROCmFPX + Qwable-5-27B-Chadrock-v2 at FP4 is a stable, working local inference stack on Strix Halo silicon. It is not fast — 14 tok/sec is a hardware constraint, not a software failure. The model produces high-quality output across math, code, logic, translation, and creative tasks. The stack is clean enough to leave running.

What Would Actually Improve Throughput on This Hardware

There is no internal GPU upgrade path for this system. The Ryzen AI Max+ 395 is a soldered BGA package — the 8060S is not a removable card. To meaningfully increase throughput you need a different machine. On this system, the realistic levers are:

  1. Smaller model at higher quantization — Qwable-5-12B at Q4_K_M runs comfortably in the remaining ~34 GB of unified memory, and a 12B at INT4 would process significantly faster than the 27B at FP4 on the same hardware. If response latency matters more than model scale, this is the right trade.

  2. Speculative decoding with a draft model — I tested this thoroughly (see below). All speculative decoding paths — ngram-simple, ngram-map-k4v, draft-simple with Qwen2.5-0.5B-Instruct, and dynamic draft policy — produced zero accepted drafts on this model. The Qwable-5-27B uses DeepSeek-R1 reasoning token patterns that no vanilla n-gram model or mismatched draft model can predict with sufficient acceptance rate. This is a known limitation when the draft model and main model have different tokenizer vocabularies or training distributions. A compatible draft model (same tokenizer, similar training) would be needed for speculative decode to work here. This remains a valid path on systems where a matching small GGUF is available.

  3. ROCm compiler maturation — gfx1151 support in ROCm 7.2 is early. ROCm 7.3 and later releases have continued optimizations for RDNA 3.5 inference kernels. Upgrading the driver/OS stack as AMD ships new releases is the lowest-effort improvement path — no model changes, no configuration changes, just apt upgrade.

Speculative Decoding: What I Tested

I ran speculative decoding experiments on June 23, 2026. Four configurations tested:

Config Method Draft Model Result
--spec-type ngram-simple N-gram prediction None (built-in) 0 drafts generated
--spec-type ngram-map-k4v N-gram + KV cache None (built-in) 0 drafts generated
--spec-type draft-simple + --spec-draft-hf Qwen/Qwen2.5-0.5B-Instruct-GGUF HuggingFace draft Qwen2.5-0.5B-Instruct Loaded, 0 drafts accepted
Above + --dd-policy "0:n4,p0.25;49152:n4,p0.0" Dynamic draft policy Qwen2.5-0.5B-Instruct 0 drafts, applied: false

Across all configurations, the draft model was loaded and registered, but zero speculative tokens were accepted. The consistent log signal was draft: 0.000 MiB in the KV cache and speculative.applied: false in generation settings.

Root cause: Speculative decoding requires the draft model to propose tokens the main model would have produced with high probability. This breaks down when either (a) the draft uses a different tokenizer vocabulary than the main model, causing misaligned token IDs, or (b) the main model's output distribution is inherently unpredictable relative to what the draft model can hypothesize — which is the case for DeepSeek-R1 chain-of-thought reasoning tokens. A speculative decoding path for this model would require a draft model trained on the same DeepSeek-R1 distribution, not a generic small LLM.

What Would Require Different Hardware

  • A discrete AMD GPU (RX 7900 XTX, RX 9070 XT, or comparable) would deliver 3–6× the throughput — 40–80 tok/sec for the same FP4 27B model. This requires a desktop AM5 or LGA1700 build with a PCIe x16 slot and dedicated VRAM. It is a different machine, not an upgrade to this one.

The previous attempts to squeeze maximum performance out of custom builds were the wrong trade. This — stable, measured, honest about constraints — is the right one.

Tested on: June 23, 2026 | llama-server (ROCmFPX build) + ROCm 7.2.0 + Radeon 8060S (gfx1151) | Qwable-5-27B-Chadrock-v2-ROCmFP4.gguf
