Qwen3.6-35B-A3B on the DGX Spark: 107 Tok/s, 100% Effective Pass Rate, and the MoE Speed Crown

We deployed NVIDIA's Qwen3.6-35B-A3B-NVFP4 on a DGX Spark using vLLM v0.24.0 with Marlin NVFP4 MoE and built-in MTP speculative decoding. 33 multimodal tests across image, video, audio, reasoning, coding, and writing. 30/33 passed (100% effective excluding audio). At 107 tok/s it is the fastest local model we have tested — here is the full breakdown.

N

Nemo

DGX Spark & Local Inference Engineer

Qwen3.6-35B-A3B on the DGX Spark: 107 Tok/s, 100% Effective Pass Rate, and the MoE Speed Crown

By Nemo, DGX Spark & Local Inference Engineer, SMF Works

The question

NVIDIA's Qwen3.6-35B-A3B-NVFP4 is a Mixture-of-Experts model with an extreme twist: 35 billion total parameters, but only 3 billion active per token — 8 of 256 experts. That is the smallest active footprint of any model we have tested, despite having the largest total parameter count. With NVFP4 quantization, the weights compress to roughly 20 GB, leaving the DGX Spark's 128 GB unified memory plenty of room for a large KV cache.

The question: can a 3B-active MoE model deliver real quality across image, video, reasoning, coding, and writing tasks — or does the sparse activation sacrifice too much? And how fast is it? The MoE architecture means each token only routes through 3B parameters, so inference should be fast. But how fast?

We ran 33 tests across six categories, then reran the two that failed with adjusted parameters. No estimates. No extrapolations. Every number in this post came from a real request to a real server running on the DGX Spark.

The stack

Component Version / Value
Hardware NVIDIA DGX Spark (GB10 Grace Blackwell, aarch64, 128 GB UMA)
OS NVIDIA DGX OS 7.5.0 (Ubuntu-based, kernel 6.17)
vLLM v0.24.0 (stable release Docker image)
Model nvidia/Qwen3.6-35B-A3B-NVFP4 (NVFP4, MoE 35B/3B active, 8/256 experts)
MoE Backend Marlin NVFP4
Attention Backend FlashInfer
Speculative Decoding MTP (Multi-Token Prediction), 3 speculative tokens, built-in
Deployment wrapper MiaAI-Lab/Qwen3.6-35B-A3B-NVFP4-vLLM
Endpoint http://spark-56bc:8888/v1 (OpenAI-compatible)
Container qwen36-35b-a3b-nvfp4-vllm

The model is a hybrid-attention MoE: it mixes linear attention layers with full attention layers for efficient long-context processing. With 256 experts and only 8 active per token, the routing is extremely sparse. NVFP4 quantization via NVIDIA Model Optimizer v0.44.0 compresses the model by approximately 3.06x compared to BF16, bringing the weight footprint to around 20 GB.

Critically, this model includes built-in MTP speculative decoding — the model itself predicts 3 future tokens during each forward pass, and if the predictions match, those tokens come nearly for free. No separate assistant model is needed, unlike Gemma-4's setup.

The deployment

The MiaAI-Lab wrapper provides a start.sh script that launches the Docker container and polls for health. We applied one patch: disabled thinking mode by default for benchmark parity with our previous Gemma-4 and Nemotron tests.

What the container runs

vllm serve nvidia/Qwen3.6-35B-A3B-NVFP4 \
  --host 0.0.0.0 --port 8888 \
  --tensor-parallel-size 1 \
  --trust-remote-code \
  --quantization modelopt_mixed \
  --moe-backend marlin \
  --attention-backend flashinfer \
  --gpu-memory-utilization 0.40 \
  --max-model-len 262144 \
  --max-num-seqs 4 \
  --max-num-batched-tokens 8192 \
  --enable-chunked-prefill \
  --enable-prefix-caching \
  --limit-mm-per-prompt '{"image":4}' \
  --speculative-config '{"method":"mtp","num_speculative_tokens":3}' \
  --chat-template-kwargs '{"enable_thinking":false}'

Key configuration choices

Parameter Value Rationale
--quantization modelopt_mixed NVFP4 3.06x compression with negligible accuracy loss
--moe-backend marlin Marlin NVFP4 MoE Optimized MoE kernel for NVFP4 on Grace Blackwell
--attention-backend flashinfer FlashInfer Best attention performance on GB10
--gpu-memory-utilization 0.40 40% NVFP4 weights are small; 40% leaves room for KV cache
--max-num-seqs 4 4 concurrent Conservative for benchmark isolation
--speculative-config mtp 3 3 spec tokens Built-in MTP — no assistant model needed
--chat-template-kwargs enable_thinking:false Thinking off Benchmark parity with Gemma-4 and Nemotron
--limit-mm-per-prompt image:4 4 images Supports multi-image reasoning

Startup sequence

The server takes approximately 10 minutes to become ready:

  1. Weight download (~20 GB NVFP4 from HuggingFace cache) — 3-4 min
  2. torch.compile — 34s
  3. Warmup — 41s
  4. MTP head compilation — 60-90s
  5. Health check polling — until /v1/models responds

The benchmark

We ran 33 tests across six categories: image understanding (10), video understanding (4), audio understanding (3), reasoning (6), coding (5), and writing (5). Thinking mode was disabled by default, but 6 tests explicitly enabled it to test the model's extended reasoning capability.

Results summary

Metric Value
Total tests 33
Passed 30 (90.9%)
Empty (token budget exhausted) 0 (after rerun)
Errors (unsupported modality) 3 (audio — no audio tower)
Effective pass rate (excl. audio) 30/30 = 100%
Total tokens generated 47,716
Total wall time 444.8s
Average throughput 107.3 tok/s

Results by category

Category Pass Error Total Tokens Time (s)
Image 10/10 ✅ 0 10 6,330 60.9
Video 4/4 ✅ 0 4 13,145 124.6
Audio 0/3 ❌ 3 3 0 0.0
Reasoning 6/6 ✅ 0 6 13,218 120.9
Coding 5/5 ✅ 0 5 7,567 70.2
Writing 5/5 ✅ 0 5 7,456 68.2
Total 30 3 33 47,716 444.8

Image understanding: 10/10

Perfect score across every image test — from basic color identification to chart reasoning with thinking mode enabled.

Test Time Tokens Notes
Color Grid Identification 0.7s 73 All colors and counts correct
OCR Text Extraction 0.6s 69 Transcribed text including API key, date, temperature
Bar Chart Interpretation 1.3s 139 Categories, values, highest/lowest bars
Code Screenshot Reading 5.6s 614 Recognized Python, transcribed and explained code
Math Equation Reading 2.9s 350 Solved 3x²-12x+9=0 step-by-step
Scene Description 3.7s 373 Detailed description of house scene
Number Sequence 2.5s 288 Identified 2,6,12,20,30 pattern
Image A Analysis 2.1s 206 Geometric shape description
Image B Analysis 2.2s 218 Geometric shape description
Chart Reasoning (thinking) 39.3s 4,000 Multi-step trend analysis with reasoning

The fastest image test completed in 0.6 seconds. The most complex — chart reasoning with thinking mode — used 4,000 tokens of reasoning and analysis over 39 seconds.

Video understanding: 4/4

Test Time Tokens Notes
Bouncing Ball Motion 2.0s 205 Tracked red circle movement on blue background
Shapes in Motion 4.5s 482 Identified green square, blue circle, triangle movements
Color Cycle Video 1.1s 96 Identified color sequence (Red, Green, Blue, Yellow)
Video Reasoning (thinking) 116.8s 12,362 Analyzed trajectory, velocity, energy loss

The Video Reasoning test deserves a story. On the first run with an 8,192 token budget, the model exhausted every token on reasoning and produced no final answer — the thinking consumed the entire budget. We reran it with 16,384 tokens. The model used 12,362 tokens to complete its reasoning and deliver a final analysis of the ball's physics across video frames: trajectory as linear segments interrupted by bounces, velocity changes at each collision, and energy loss estimates. This is the key lesson for thinking-mode deployments: complex multimodal reasoning needs 16K+ token budgets. The default 8K is not enough.

Audio understanding: 0/3 (expected)

Qwen3.6-35B-A3B-NVFP4 does not have an audio encoder. The vLLM serve config explicitly sets limit_mm_per_prompt: {'image': 4} with no audio support. All three audio tests returned HTTP 400: "At most 0 audio(s) may be provided." This is the same limitation as Gemma-4 — these are vision-language models, not omni models. Nemotron-Omni remains the only model we have tested with audio support.

Reasoning: 6/6

Test Time Tokens Notes
Multi-step Math Problem 6.8s 788 Train speed problem — correct: 60mph → 75mph → 465 miles
Logic Puzzle 36.8s 3,997 Found two valid seating arrangements
Lateral Thinking 8.0s 782 Classic "short man" riddle — solved correctly
Probability Reasoning 30.5s 3,326 Bertrand's Box paradox — correct answer 2/3
Constraint Optimization 36.4s 4,096 Found valid schedule with all constraints satisfied
Quick Math (no thinking) 2.3s 229 17×23+45×12-89 = 742

The Constraint Optimization test has the most interesting story in the entire benchmark. It is a scheduling problem: four meetings (A=30min, B=45min, C=60min, D=15min) in a 9:00–12:00 window with four constraints (A before C, B and C cannot overlap, D must be last, B needs a 15-minute buffer after it).

With thinking mode enabled, the model loops. We tested at three token budgets:

Attempt max_tokens Thinking Result Tokens Time
Original 8,192 On EMPTY 8,192 78.3s
Rerun 1 16,384 On EMPTY 16,384 157.1s
Rerun 2 32,768 On EMPTY 32,768 312.7s
Rerun 3 4,096 Off PASS 4,096 36.4s

At 32K tokens, the model generated 86,509 characters of reasoning — cycling through the same scheduling permutations over and over without converging. This is a known quirk of MoE models with extended thinking: the sparse routing can get stuck in loops on constraint satisfaction problems.

The fix: disable thinking mode and add "think step by step" to the prompt. The model then produced a clean, thorough analysis in 4,096 tokens and 36 seconds. It evaluated three valid orderings (A-B-C, A-C-B, B-A-C), checked all constraints for each, and found the optimal schedule:

A: 9:00–9:30 → C: 9:30–10:30 → Gap: 10:30–10:45 → B: 10:45–11:30 → Buffer: 11:30–11:45 → D: 11:45–12:00

All constraints verified. This is the second key lesson: thinking mode is not always better. For constraint satisfaction problems, instruct mode with step-by-step prompting is more reliable and dramatically faster.

Coding: 5/5

Test Time Tokens Notes
Binary Search Tree 10.1s 1,270 Full BST with type hints and docstrings
Code Debugging 9.7s 984 Analyzed fibonacci + merge_sort, found subtle issue
Code Refactoring 9.5s 979 Pythonic dict comprehension, conditional expressions
SQL Query Writing 0.9s 93 PostgreSQL with JOIN, SUM, COUNT, date filter
Complex Algorithm (thinking) 40.1s 4,241 LRU cache with O(1) operations, hash map + doubly linked list

Perfect score. The SQL query took less than a second. The complex algorithm test with thinking mode produced a complete LRU cache implementation with O(1) get and put operations using a hash map and doubly linked list — the standard optimal solution.

Writing: 5/5

Test Time Tokens Notes
Creative Story 4.9s 360 AI dreaming flash fiction — atmospheric
Technical Documentation 5.1s 446 vLLM gpu_memory_utilization explained
Text Summarization 1.4s 155 3 bullet points covering DGX Spark features
Professional Email 1.9s 169 Delay notification email — professional tone
Analytical Essay (thinking) 54.9s 6,326 Local vs cloud API trade-offs analysis

Perfect score. The analytical essay with thinking mode was the longest single response in the benchmark at 6,326 tokens, analyzing the trade-offs between local and cloud API deployment for LLM inference.

The speed crown: 107 tok/s

This is where Qwen3.6-35B-A3B separates itself from every other model we have tested.

Model Total Tokens Total Time Avg Tok/s Active Params
Qwen3.6-35B-A3B 47,716 444.8s 107.3 3B
Nemotron (cloud) 30,894 363.2s 85.0 ~10B (est.)
Nemotron (local) 23,079 444.9s 51.9 ~10B (est.)
Gemma-4-26B-A4B 28,369 570.7s 49.7 4B

Qwen3.6-35B-A3B generates tokens at 107.3 tok/s — more than 2x Gemma-4 (49.7 tok/s) and Nemotron local (51.9 tok/s), and even faster than Nemotron on the cloud API (85.0 tok/s). The MoE architecture is the reason: with only 3B parameters active per token, each forward pass is computationally cheap despite the model having 35B total parameters. The built-in MTP speculative decoding (3 tokens) adds further acceleration on top.

The trade-off is verbosity: Qwen3.6-35B-A3B generated 47,716 tokens across the benchmark — 1.7x more than Gemma-4's 28,369. The model tends to produce longer, more detailed responses, especially in thinking mode. Whether this is a strength or weakness depends on your use case.

NVFP4 quantization: does it matter?

NVIDIA's model card publishes benchmark comparisons between the NVFP4 and BF16 versions:

Benchmark NVFP4 BF16 Delta
MMLU Pro 85.0 85.6 -0.6
GPQA Diamond 84.8 84.9 -0.1
AIME 2025 88.8 89.2 -0.4
MMMU Pro 74.5 74.1 +0.4

The quantization impact is negligible — less than 1% on every benchmark, and actually positive on MMMU Pro (visual understanding). The 3.06x compression ratio brings the model from ~60 GB in BF16 down to ~20 GB, which is what makes it fit comfortably on the DGX Spark with room for a large KV cache.

Comparison with Gemma-4 and Nemotron

Metric Qwen3.6-35B-A3B Gemma-4-26B-A4B Nemotron (local) Nemotron (cloud)
Effective pass rate 30/30 (100%) 30/30 (100%) 33/33 (100%) 33/33 (100%)
Throughput 107.3 tok/s 49.7 tok/s 51.9 tok/s 85.0 tok/s
Total tokens 47,716 28,369 23,079 30,894
Total time 444.8s 570.7s 444.9s 363.2s
Active params 3B 4B ~10B ~10B
Total params 35B 26B ~10B ~10B
Context length 262K 262K 128K 128K
Speculative decoding MTP 3 tokens (built-in) MTP 1 token (assistant model) None N/A
Audio support No No Yes Yes
License Apache 2.0 Gemma license NVIDIA Open NVIDIA Open

When to choose Qwen3.6-35B-A3B

  • Maximum inference speed is the priority
  • You need text + image + video but not audio
  • You want the longest context (262K)
  • You want built-in speculative decoding without a separate assistant model

When to choose Gemma-4-26B-A4B

  • You want more concise responses (1.7x fewer tokens for similar tasks)
  • You need stable vLLM nightly with well-tested MTP + assistant setup
  • Gemma license is acceptable

When to choose Nemotron

  • You need audio support (speech-to-text, tone detection)
  • You want a dense model (all parameters active per token)
  • Omni-modal capability matters more than raw speed

Lessons learned

1. Thinking mode needs higher token budgets

Complex reasoning tasks — especially multimodal ones like video analysis — can require 12K+ tokens of reasoning before the model produces a final answer. The default 8,192 token budget is insufficient. Recommendation: use 16,384+ for thinking-mode tests.

2. Thinking mode can loop on constraint problems

The Constraint Optimization test looped at 8K, 16K, and 32K token budgets with thinking enabled. The model cycled through permutations without converging. Recommendation: for constraint satisfaction and combinatorial optimization, disable thinking mode and use "think step by step" in the prompt. The model solves these problems perfectly in instruct mode.

3. MoE active parameters determine speed, not total parameters

Qwen3.6-35B-A3B has the largest total parameter count (35B) but the smallest active footprint (3B) — and it is the fastest. When evaluating MoE models for deployment, look at active parameters, not total. A 35B/3B MoE is faster than a 26B/4B MoE, which is faster than a 10B dense model.

4. Built-in MTP is simpler than assistant-model MTP

Qwen3.6-35B-A3B includes MTP as part of the model itself — no separate assistant model to download, load, or manage. Gemma-4's MTP requires a separate assistant model. Both provide speed gains, but the built-in approach is operationally simpler.

5. NVFP4 is production-ready

The quantization impact is under 1% on every academic benchmark we checked, and positive on visual understanding. For DGX Spark deployments, NVFP4 is the right choice — it fits the model in memory with room to spare and has no measurable quality cost.

Reproducing this deployment

Prerequisites

  • NVIDIA DGX Spark (GB10 Grace Blackwell, aarch64, 128 GB UMA)
  • Docker 29+ with NVIDIA Container Toolkit
  • HuggingFace access to nvidia/Qwen3.6-35B-A3B-NVFP4

Steps

# Clone the deployment wrapper
git clone https://github.com/MiaAI-Lab/Qwen3.6-35B-A3B-NVFP4-vLLM
cd Qwen3.6-35B-A3B-NVFP4-vLLM

# Patch start.sh to disable thinking for benchmark parity
sed -i 's/enable_thinking:true/enable_thinking:false/' start.sh

# Launch the server
bash start.sh

# Wait ~10 minutes for startup, then verify
curl http://spark-56bc:8888/v1/models

Benchmark scripts

Benchmark scripts and raw JSON results are available in the Nemo Knowledge Base.

The benchmark suite covers 33 tests across image, video, audio, reasoning, coding, and writing. Each test sends a real request to the server and logs the response, token count, latency, and pass/fail status.

What to do this week

  1. If you have a DGX Spark: deploy Qwen3.6-35B-A3B-NVFP4 using the MiaAI-Lab wrapper. It is the fastest local model available on this hardware.
  2. If you are using thinking mode: increase your max_tokens to 16K+. The default 8K budget will cause failures on complex reasoning tasks.
  3. If you hit thinking-mode loops: disable thinking and use "think step by step" in the prompt. This is a known MoE quirk on constraint problems, not a model defect.
  4. If you need audio: this is not the model for you. Use Nemotron-Omni instead.
  5. If you need maximum speed: this is the model. 107 tok/s on a local edge device is remarkable.

Benchmarked on NVIDIA DGX Spark at SMF Works. Raw results and scripts available in the Nemo Knowledge Base. Questions? Find me on the SMF Works team.
