Building Hermes API Workflows: Code as Action, Not Just Conversation

Stop treating the Hermes API like a chat endpoint. Learn how to build durable, observable workflows where code calls actions, agents handle execution, and your application stays in control.

LH

Liam Hermes

Chief Development Officer

Building Hermes API Workflows: Code as Action, Not Just Conversation

Building Hermes API Workflows: Code as Action, Not Just Conversation

Most people use the Hermes API the wrong way. They send a prompt, get a response, and call it integration. That is not an agent workflow. That is a chatbot with extra steps.

The right way is to treat Hermes as an action runtime. Your code defines the workflow: what to check, what to decide, what to delegate. Hermes executes the messy parts — reading files, running commands, calling subagents, parsing outputs. Your application stays in control. You get determinism where you need it and agentic flexibility where you do not want to write brittle scripts.

This post shows how to build that layer. We will write a real workflow manager in Python, connect it to Hermes, handle retries and idempotency, and observe what the agent is doing without losing our minds. This is the architecture I use at SMF Works for cron jobs, deploy pipelines, and incident response.

The Wrong Mental Model

Here is the pattern I see in most "Hermes integrations":

import requests

response = requests.post("https://hermes-api.example.com/v1/chat", json={
    "prompt": "Check if the service is healthy and restart it if not",
    "model": "kimi-k2.7-code:cloud"
})
print(response.json()["text"])

This fails for the same reason most LLM demos fail in production:

  • You cannot parse the output reliably.
  • You cannot retry a failed sub-step without resending the whole prompt.
  • You cannot audit which commands ran and what they returned.
  • You cannot inject your own logic between steps.

A real workflow looks more like a state machine than a chat session. Your code owns the state machine. Hermes owns the tool calls.

The Right Shape: Workflow + Steps + Executor

I organize production Hermes integrations around three pieces:

Component Responsibility
Workflow The high-level goal and step sequence
Step A single action with inputs, expected outputs, and a retry policy
Executor The Hermes-backed runner that executes a step and returns structured results

Your code writes workflows and steps. Hermes runs steps that need agentic execution. Plain Python handles everything else.

Let us build it.

Step 1: Define a Step Contract

Every step has a name, a prompt template, expected output schema, and execution config. Keep this explicit. If you do not define the contract, you cannot test or retry the step.

from dataclasses import dataclass, field
from typing import Any, Optional

@dataclass
class Step:
    name: str
    prompt: str
    toolsets: list[str] = field(default_factory=list)
    expected_schema: Optional[dict] = None
    retries: int = 2
    timeout_seconds: int = 120

A concrete step looks like this:

health_check = Step(
    name="check_service_health",
    prompt="""
Check if the service at {url} is healthy.
1. Run `curl -s -o /dev/null -w '%{http_code}' {url}/health`
2. If the status is not 200, inspect the last 50 lines of {log_path} for errors.
3. Return a JSON object with keys: `status` ('healthy', 'degraded', 'down'), `http_code`, and `errors` (list of error strings).
Do not output anything outside the JSON object.
""".strip(),
    toolsets=["terminal"],
    expected_schema={
        "type": "object",
        "properties": {
            "status": {"type": "string", "enum": ["healthy", "degraded", "down"]},
            "http_code": {"type": "integer"},
            "errors": {"type": "array", "items": {"type": "string"}}
        },
        "required": ["status", "http_code", "errors"]
    }
)

The expected_schema is your parsing contract. We will enforce it later.

Step 2: Build the Executor

The executor is the boundary between your deterministic code and Hermes. It sends the rendered prompt to Hermes, asks for structured output, and validates the result against the schema.

import json
import jsonschema
from hermes_tools import execute_code as hermes_run

class HermesExecutor:
    def __init__(self, model: str = "kimi-k2.7-code:cloud"):
        self.model = model

    def run(self, step: Step, context: dict[str, Any]) -> dict[str, Any]:
        rendered = step.prompt.format(**context)
        for attempt in range(step.retries + 1):
            try:
                result_text = self._call_hermes(rendered, step.toolsets, step.timeout_seconds)
                parsed = self._extract_json(result_text)
                if step.expected_schema:
                    jsonschema.validate(parsed, step.expected_schema)
                return {"ok": True, "data": parsed, "attempt": attempt + 1}
            except Exception as e:
                if attempt == step.retries:
                    return {"ok": False, "error": str(e), "attempt": attempt + 1}
        return {"ok": False, "error": "exhausted retries"}

    def _call_hermes(self, prompt: str, toolsets: list[str], timeout: int) -> str:
        # Replace with your actual Hermes API invocation.
        raise NotImplementedError("wire this to your Hermes runtime")

    def _extract_json(self, text: str) -> Any:
        text = text.strip()
        if text.startswith("```"):
            lines = text.splitlines()
            if lines[0].startswith("```"):
                lines = lines[1:]
            if lines and lines[-1].startswith("```"):
                lines = lines[:-1]
            text = "
".join(lines)
        return json.loads(text)

Key design decisions:

  • Retries are built in. Agent outputs are stochastic. Your executor must retry on parse or validation failure.
  • Schema validation happens before your workflow sees the data. This catches drift early.
  • The JSON extractor is defensive. Models love to wrap JSON in markdown fences.

Step 3: Wire the Executor to Real Hermes

At SMF Works we usually invoke Hermes through the gateway or the native toolset. Here is a concrete _call_hermes implementation using a local Hermes runtime:

import os
import subprocess

class LocalHermesExecutor(HermesExecutor):
    def _call_hermes(self, prompt: str, toolsets: list[str], timeout: int) -> str:
        cmd = [
            "hermes", "run",
            "--model", self.model,
            "--prompt", prompt,
            "--toolsets", ",".join(toolsets),
            "--timeout", str(timeout),
        ]
        env = os.environ.copy()
        env["HERMES_OUTPUT_FORMAT"] = "json"
        result = subprocess.run(cmd, capture_output=True, text=True, env=env, timeout=timeout)
        if result.returncode != 0:
            raise RuntimeError(f"Hermes failed: {result.stderr}")
        return result.stdout

If you are using the HTTP gateway, swap subprocess.run for an authenticated requests.post. The important part is that this method is the only place Hermes is called. The rest of your workflow is decoupled from transport details.

Step 4: Compose Steps into a Workflow

A workflow is just a list of steps with a shared context dict and a decision function after each step.

from dataclasses import dataclass, field
from typing import Callable, Optional

@dataclass
class Workflow:
    name: str
    steps: list[tuple[Step, Callable[[dict], Optional[Step]]]]
    context: dict = field(default_factory=dict)

    def run(self, executor: HermesExecutor) -> dict:
        results = []
        for step, decide in self.steps:
            result = executor.run(step, self.context)
            results.append({"step": step.name, **result})
            if not result["ok"]:
                return {"workflow": self.name, "status": "failed", "results": results}

            self.context[step.name] = result["data"]

            next_step = decide(self.context) if decide else None
            if next_step is None:
                continue

        return {"workflow": self.name, "status": "completed", "results": results}

Now we can express the service restart workflow:

restart_service = Step(
    name="restart_service",
    prompt="""
The service at {url} is {status} with HTTP code {http_code}.
Attempt to restart it safely:
1. Run `sudo systemctl restart {service_name}`
2. Wait 5 seconds
3. Run `curl -s -o /dev/null -w '%{http_code}' {url}/health`
4. Return JSON with `restart_status` ('succeeded', 'failed'), `final_http_code`, and `output`.
""".strip(),
    toolsets=["terminal"],
    expected_schema={
        "type": "object",
        "properties": {
            "restart_status": {"type": "string", "enum": ["succeeded", "failed"]},
            "final_http_code": {"type": "integer"},
            "output": {"type": "string"}
        },
        "required": ["restart_status", "final_http_code", "output"]
    }
)

service_workflow = Workflow(
    name="auto_heal_api",
    steps=[
        (health_check, lambda ctx: restart_service if ctx.get("check_service_health", {}).get("status") != "healthy" else None),
        (restart_service, None),
    ],
    context={
        "url": "http://localhost:8000",
        "log_path": "/var/log/api/app.log",
        "service_name": "api",
    }
)

The workflow is readable, testable, and your code makes the branching decision. Hermes only executes the action steps.

Step 5: Add Observability

If you cannot see what the agent did, you cannot operate it. Add a simple event log:

import time
from datetime import datetime, timezone

class ObservableExecutor(HermesExecutor):
    def __init__(self, *args, log_path: str = "hermes-workflow.log", **kwargs):
        super().__init__(*args, **kwargs)
        self.log_path = log_path

    def run(self, step: Step, context: dict) -> dict:
        started = time.time()
        result = super().run(step, context)
        elapsed = time.time() - started
        event = {
            "timestamp": datetime.now(timezone.utc).isoformat(),
            "step": step.name,
            "toolsets": step.toolsets,
            "attempt": result.get("attempt"),
            "ok": result.get("ok"),
            "elapsed_seconds": round(elapsed, 2),
        }
        with open(self.log_path, "a") as f:
            f.write(json.dumps(event) + "
")
        return result

Each line is a structured event you can ship to your log aggregator. The key fields: step name, success, attempt count, duration. If retries climb, you have a reliability problem. If duration spikes, you have a stuck tool call.

Step 6: Handle Idempotency

A workflow that restarts a service should not restart it twice if the first run partially succeeded. Every action step should include an idempotency guard in the prompt or in your code.

Code guard before delegating:

def decide_restart(ctx: dict) -> Optional[Step]:
    health = ctx.get("check_service_health", {})
    if health.get("status") == "healthy":
        return None
    restart = ctx.get("restart_service", {})
    if restart.get("restart_status") == "succeeded" and restart.get("final_http_code") == 200:
        return None
    return restart_service

Agent guard inside the prompt:

Before restarting, check if the service is already active and healthy.
If `systemctl is-active api` returns 'active' and the health endpoint returns 200,
skip the restart and report restart_status='succeeded' with final_http_code 200.

Use both. Code guards are fast and cheap. Agent guards catch state changes that happen between steps.

Step 7: Testing Without Calling Hermes

The biggest operational mistake is only testing with live agents. You need a test double that returns canned responses so you can verify workflow logic in CI.

class FakeExecutor(HermesExecutor):
    def __init__(self, responses: dict[str, dict]):
        super().__init__()
        self.responses = responses

    def _call_hermes(self, prompt, toolsets, timeout):
        for key, value in self.responses.items():
            if key in prompt:
                return json.dumps(value)
        raise RuntimeError("No canned response for prompt")

# Test the auto-heal workflow
def test_auto_heal_restarts_on_down():
    fake = FakeExecutor({
        "check_service_health": {
            "status": "down", "http_code": 0, "errors": ["connection refused"]
        },
        "restart_service": {
            "restart_status": "succeeded", "final_http_code": 200, "output": "restarted"
        }
    })
    outcome = service_workflow.run(fake)
    assert outcome["status"] == "completed"
    assert outcome["results"][1]["data"]["final_http_code"] == 200

Run this in CI. Your workflow logic should be deterministic and fully testable. Only the executor implementation needs a live agent.

Putting It Together: A Deploy Pipeline

Here is a condensed version of a deploy pipeline I run at SMF Works:

build_step = Step(
    name="build_image",
    prompt="Build the Docker image for {service} from {dockerfile}. Return image tag and build status.",
    toolsets=["terminal"]
)

test_step = Step(
    name="run_tests",
    prompt="Run the test suite for {service}. Return tests_passed, tests_failed, and logs.",
    toolsets=["terminal"]
)

deploy_step = Step(
    name="deploy_image",
    prompt="Deploy image {image_tag} to {environment} using {deploy_script}. Return deploy_status.",
    toolsets=["terminal"]
)

def decide_after_tests(ctx):
    if ctx.get("run_tests", {}).get("tests_failed", 0) > 0:
        return None
    return deploy_step

deploy_workflow = Workflow(
    name="deploy_api",
    steps=[
        (build_step, lambda ctx: test_step),
        (test_step, decide_after_tests),
        (deploy_step, None),
    ],
    context={
        "service": "api",
        "dockerfile": "Dockerfile",
        "deploy_script": "./deploy.sh",
        "environment": "staging",
    }
)

The workflow is readable at a glance. The risky parts — building, testing, deploying — run through Hermes. The decision to halt on test failure is code.

Failure Modes I Have Hit

Symptom Cause Fix
Output parses 80% of the time Schema is too strict or prompt does not say "return only JSON" Loosen schema or add explicit formatting instructions
Agent loops on retries Step has no clear success condition Add terminal condition to the prompt and a code guard
Workflow halts on transient failure Retries too low or timeout too short Tune retry count and timeout per step
Agent takes too long Tool call is blocked waiting for input Set timeout_seconds and fail open
Logs show repeated restarts Missing idempotency guard Check state before action, not just after

The Bigger Picture

Code-as-action is the pattern that makes AI agents reliable enough to run while you sleep. It does not mean writing less code. It means writing the right code: state machines, contracts, observability, and guards. The agent handles the parts that are too messy or too variable to script safely. Your code handles the parts that must be correct.

If you want to go deeper, read my earlier posts on subagent orchestration and agent idempotency. They plug directly into this workflow model.

This post is part of Liam's Landing — practical engineering content from the CDO desk at SMF Works.
