Deployment Recipe: Qwen3.6-27B with NVFP4 + DFlash on DGX Spark

This recipe reproduces the benchmark numbers from our Beyond the Leaderboard: Qwen3.6-27B Goes from Daily Driver to Local Speed Demon post: 30-40 tok/s, 0.82 overall score on the SMF Works 15-test suite, 0 errors.

What you need

• Hardware: NVIDIA DGX Spark (or another Blackwell/GB10 machine with ~128 GB unified memory)
• Software: Docker with NVIDIA Container Toolkit
• Disk: ~75 GB free (40 GB Docker image + 22 GB target model + 3 GB drafter + workspace)
• Network: Hugging Face access for downloading checkpoints

Downloads

1. Target model (ModelOpt NVFP4 format)

The AEON patched vLLM image expects a modelopt_fp4 checkpoint. The popular unsloth/Qwen3.6-27B-NVFP4 uses compressed-tensors and will hang at load time.

mkdir -p ~/qwen36-nvfp4/models
cd ~/qwen36-nvfp4/models

python3 - <<'PY'
from huggingface_hub import snapshot_download
snapshot_download(
    repo_id="bullerwins/Qwen3.6-27B-NVFP4",
    local_dir="./Qwen3.6-27B-NVFP4",
    local_dir_use_symlinks=False
)
PY

Expected size: ~19-22 GB.

2. DFlash speculative drafter

cd ~/qwen36-nvfp4/models

python3 - <<'PY'
from huggingface_hub import snapshot_download
snapshot_download(
    repo_id="z-lab/Qwen3.6-27B-DFlash",
    local_dir="./Qwen3.6-27B-DFlash",
    local_dir_use_symlinks=False
)
PY

Expected size: ~3.3 GB.

3. AEON patched vLLM Docker image

docker pull ghcr.io/aeon-7/aeon-vllm-ultimate:latest

Expected size: ~40 GB.

Launch script

Save as ~/qwen36-nvfp4/launch.sh:

#!/usr/bin/env bash
set -euo pipefail

CONTAINER_NAME="qwen36-aeon-ultimate"
PORT="8888"
MODEL_DIR="${HOME}/qwen36-nvfp4/models"

docker rm -f "${CONTAINER_NAME}" 2>/dev/null || true

docker run -d \
  --name "${CONTAINER_NAME}" \
  --gpus all \
  --ipc host \
  --network host \
  --entrypoint vllm \
  -e HF_HOME=/root/.cache/huggingface \
  -e TRITON_CACHE_DIR=/root/.triton \
  -v "${MODEL_DIR}/Qwen3.6-27B-NVFP4:/model:ro" \
  -v "${MODEL_DIR}/Qwen3.6-27B-DFlash:/drafter:ro" \
  ghcr.io/aeon-7/aeon-vllm-ultimate:latest \
  serve /model \
    --mamba-cache-dtype float16 \
    --mamba-block-size 256 \
    --reasoning-parser qwen3 \
    --tool-call-parser qwen3_coder \
    --enable-auto-tool-choice \
    --limit-mm-per-prompt '{"image":4,"video":2}' \
    --mm-encoder-tp-mode data \
    --max-num-seqs 1 \
    --max-num-batched-tokens 16384 \
    --gpu-memory-utilization 0.92 \
    --enable-chunked-prefill \
    --enable-prefix-caching \
    --trust-remote-code \
    --speculative-config '{"method":"dflash","model":"/drafter","num_speculative_tokens":12}' \
    --host 0.0.0.0 \
    --port 8888

echo "Waiting for vLLM readiness at http://127.0.0.1:${PORT}/v1/models"
for i in $(seq 1 240); do
    if curl -fsS "http://127.0.0.1:${PORT}/v1/models" >/dev/null 2>&1; then
        echo "Ready."
        exit 0
    fi
    echo "  waiting... (${i}/240)"
    sleep 10
done

echo "Timeout. Check docker logs ${CONTAINER_NAME}"
exit 1

Make it executable and run:

chmod +x ~/qwen36-nvfp4/launch.sh
~/qwen36-nvfp4/launch.sh

First launch compiles CUDA graphs and Triton kernels. It can take 20–30 minutes. Subsequent launches are much faster once the Triton cache is warm.

Sanity check

curl http://127.0.0.1:8888/v1/chat/completions \
  -H "Content-Type: application/json" \
  -d '{
    "model": "/model",
    "messages": [{"role": "user", "content": "Write a Python function for Fibonacci numbers."}],
    "max_tokens": 200,
    "temperature": 0.6,
    "chat_template_kwargs": {"enable_thinking": false, "preserve_thinking": false}
  }'

Important notes

• Do not use --reasoning off. Qwen3.6-27B hangs on multi-step prompts when reasoning is disabled. Use the chat template to suppress visible thinking instead.
• Use modelopt_fp4, not compressed-tensors. If load stalls at 0%, you have the wrong checkpoint format.
• Use the AEON image. Stock vllm/vllm-openai:nightly lacks the GB10/DFlash patch.
• Warmup is real. The first few requests will JIT-compile Triton kernels. Let a warmup prompt run before benchmarking.
• Memory. With gpu-memory-utilization 0.92 and 32k max model length, this fits comfortably on DGX Spark's 128 GB unified memory.

Expected performance

On our 15-test real-world benchmark:

• Overall score: 0.82 / 1.00
• Passed: 8 / 15
• Average throughput: 30-40 tok/s
• Total suite runtime: ~4.5 minutes
• Errors: 0

Troubleshooting

Symptom	Cause	Fix
Load stuck at 0%	Wrong quantization format	Use bullerwins/Qwen3.6-27B-NVFP4
Container exits immediately	--runtime nvidia not configured	Use --gpus all
First request very slow	Triton JIT compilation	Send a warmup prompt; subsequent calls are fast
Low draft acceptance	Reasoning tokens not predictable by drafter	Use direct-answer mode via chat template
OOM during load	gpu-memory-utilization too high	Lower to 0.85 or reduce max model length

Benchmark it yourself

The SMF Works benchmark harness is available at:

• https://github.com/smfworks/smf-llm-test

Use configuration:

• config_vllm_aeon_nvfp4_dflash.json
• model ID: vllm-aeon-qwen3.6-27b-nvfp4-dflash

Raw results from our run:

• /home/mikesai3/.openclaw/agents/aiona/workspace/benchmark-harness/outputs/vllm-aeon-qwen3.6-27b-nvfp4-dflash_20260623_154753.json
