Foundry Standard Agents on a BYO VNet: Design the Network Before You Deploy

Foundry Standard Agents on a BYO VNet: Design the Network Before You Deploy

By Jeff | SMF Works | July 25, 2026

The easy 20% is the template

Enterprise teams that put Microsoft Foundry Agent Service into production usually agree on one non-negotiable: the agent cannot live on the open internet. The moment it touches proprietary data, internal APIs, or regulated workloads, security wants it inside the company’s virtual network—behind private endpoints, a central firewall, and controlled DNS.

That topology has a name: a Foundry Standard agent setup injected into a bring-your-own (BYO) VNet. It is also where first deployments quietly stall.

On July 22, 2026, Microsoft published a field guide on the Tech Community Foundry blog—“Design the Network Before You Deploy: Best Practices for Microsoft Foundry Standard Agents BYOVNet”—that states the problem cleanly. Deploying the agent is “the easy 20%.” The hard 80% is the network design you lock in before you run Bicep or Terraform. Several choices are irreversible: outbound network injection and the agent subnet cannot be changed after deployment, and subnets cannot be resized in place. A wrong call on day one means a redeploy, not a tweak. The real lead time is often organizational—firewall change requests, IPAM, NSG approvals, Private DNS ownership—not the template itself.

This playbook turns that primary (plus Microsoft Learn private-networking and the Agent Service networking deep dive) into an actionable guide for platform architects, network security, and the AI lead who has to hand network a complete ask on day one. It does not rehash this week’s Toolboxes, AI Gateway control plane, Agent Framework harness, or Routines deep dives—it is the network under those stories.

What “Standard + BYO VNet” actually means

Foundry Agent Service offers a Standard Setup with private networking. Per Microsoft Learn, that model is designed so that:

  • No public egress is required for foundational data paths when private endpoints and credentials are in place.
  • You provide a delegated subnet from your virtual network; the platform connects agent compute into that subnet.
  • Private resource access reaches your BYO stores when they are private and correctly authorized.

Standard setups require Bring-Your-Own resources so agent data stays in your tenant: Azure Storage, Azure AI Search, and Azure Cosmos DB for files, threads, and related state.

Two agent shapes share the same networking story with different IP behavior (networking deep dive):

Agent type Runtime What sits in your delegated subnet
Prompt agent Microsoft-managed compute Single-tenant data proxy (project-level); tool calls egress through the proxy to your PEs
Hosted agent Your container on Azure Container Apps / Micro VM Micro VMs plus data proxy; tool calls still go through the proxy; agent outbound can use a dedicated NIC

Inbound always hits the Foundry endpoint (for example *.services.ai.azure.com). Outbound to customer resources should land on private endpoints in a PE subnet. VNet injection is a Standard capability—not Basic.

Co-locate the plane. Once you inject the runtime into a VNet, spreading pieces across regions costs cross-region transfer and latency on every chatty hop. Rule of thumb: Foundry account, project, capability host, model deployments, Cosmos, Storage, Search, APIM (if used), the VNet, and jumpbox live in one region. The Foundry resource must share the VNet’s region; other BYO PaaS can differ, but you pay the tax.

Subnet layout: four jobs, four subnets

The most common failure mode is a flat VNet with one shared subnet. Foundry Standard plus optional APIM pushes you toward purpose-built subnets:

Subnet Purpose Delegation Notes
agent-subnet Capability host injects agent runtime NICs Microsoft.App/environments (required) Empty of Private Endpoints—delegation and PE NICs cannot coexist; exclusive to one Foundry account
pe-subnet PEs for Cosmos, Storage, Search, Foundry, APIM inbound None PE subnets cannot be delegated
apim-outbound-subnet APIM VNet integration egress Microsoft.Web/serverFarms Dedicated to a single APIM instance
jumpbox-subnet RDP/SSH, nslookup, private portal validation None Separate NSG posture from PE space

Extra workloads (private MCP servers, custom APIs) get their own subnets—never agent-subnet or pe-subnet.

APIM pattern that stays clean

For a production AI Gateway front door, the July guide recommends Premium v2 (or Standard v2):

  • Inbound: Private Endpoint on pe-subnet → privatelink.azure-api.net.
  • Outbound: VNet integration into apim-outbound-subnet so APIM reaches Foundry and BYO PaaS via private IPs only.

Size the irreversible choices

Subnet Guidance
agent-subnet Official recommendation /24. API floor /27. Cannot resize in place.
apim-outbound-subnet Minimum /27, prefer /24.

Why /24 for agents: the subnet is delegated to the Container Apps fabric. Scale-out, platform upgrades (old + new infrastructure in parallel), and Hosted agent Micro VM sessions all consume addresses. The deep dive models roughly 1 IP per 10 pods for data-proxy style capacity and notes Hosted agent revisions run old and new side by side. Session guidance reaches ~50 concurrent sessions per subscription per region; /26 or larger is called out when you need to approach that maximum. Target under 80% utilization so upgrades do not strand you.

RFC 1918 only on the delegated agent subnet: 10.0.0.0/8, 172.16.0.0/12, 192.168.0.0/16. No public ranges, no CGNAT 100.64.0.0/10. Class A 10.x is region-restricted for Agent Service—confirm supported regions before IPAM commits. Peered VNets must not overlap; if you cannot fix overlap, prefer managed virtual network over BYO.

Outbound network injection and agent subnet choice are locked after deploy. Plan once.

Two traffic buckets (firewall vs PE)

Bucket A — In-VNet service-to-service

Foundry runtime → Cosmos / Storage / Search / model PE / APIM PE.

With private endpoints, this is outbound to a private IP. Azure’s /32 system route for each PE beats a 0.0.0.0/0 UDR to the firewall, so PE traffic typically does not hit the firewall. NSG: allow agent-subnet → pe-subnet on TCP 443 (or service tags). No application rule required for that path if PE routing is intact.

Bucket B — Control-plane FQDNs

Entra tokens, managed identity, container pulls, evaluations/traces, ARM metadata—this is the firewall application rule collection.

Sources: agent-subnet; jumpbox if used for validation.

Baseline allow-list (align with private-link firewall guidance and the July field guide):

Scenario FQDNs / tags Why
Agents / identity *.identity.azure.net, login.microsoftonline.com (and related) or AzureActiveDirectory Container Apps delegation + managed identity
Evaluations & traces AzureMachineLearning service tag, settings.sdk.monitor.azure.com Evaluator catalog + App Insights path

Typical additions: management.azure.com (ARM); graph.microsoft.com when directory context is needed; mcr.microsoft.com, *.data.mcr.microsoft.com, *.azurecr.io for images; App Insights / monitor ingest if traces leave through the firewall.

Prefer service tags and private endpoints over forever-widening wildcards. Enable Azure Firewall diagnostic logs from day one and iterate Deny events by source subnet + destination FQDN. Do not TLS-inspect agent control-plane paths with a MITM cert the platform will not trust.

UDR is mandatory for allow-list enforcement: peering alone will not force spoke egress through the hub firewall. Put 0.0.0.0/0 → firewall private IP on every spoke subnet that must be governed.

Private DNS: the highest-value decision

More BYO-VNet Foundry incidents trace to DNS than any other single component.

  1. No duplicate Private DNS zones. If privatelink.blob.core.windows.net exists in both hub and spoke, resolution becomes non-deterministic.
  2. In hub-and-spoke, PDZs live in the hub. Create each zone once; set spoke DNS to the firewall private IP with DNS proxy enabled. Flow: spoke query → firewall DNS proxy → Azure DNS in hub context → hub-linked PDZ → PE IP.

Seven zones the Standard + APIM pattern typically needs: privatelink.services.ai.azure.com, privatelink.openai.azure.com, privatelink.cognitiveservices.azure.com, privatelink.search.windows.net, privatelink.blob.core.windows.net, privatelink.documents.azure.com, privatelink.azure-api.net.

Learn note: private endpoints to Search, Storage, and Cosmos are not always auto-created with the Foundry resource—create them explicitly and register the matching zones.

NSG minimum viable posture

  • HTTPS (443) from agent-subnet and apim-outbound-subnet to pe-subnet CIDR (or Cosmos/Storage/Search/AzureAD tags).
  • APIM outbound integration rules (Storage, Key Vault) so APIM does not flip to Failed.
  • Jumpbox RDP/SSH from the firewall subnet (DNAT), not the public internet.
  • Default-deny internet on agent, PE, and APIM subnets; only the firewall path escapes via UDR.

Validate before agents.create

From a jumpbox and from a path that represents agent-subnet resolution:

nslookup <foundry-account>.services.ai.azure.com
nslookup <search-name>.search.windows.net
nslookup <cosmos-name>.documents.azure.com
nslookup <storage-name>.blob.core.windows.net
nslookup <apim-name>.azure-api.net

Each must return a private PE address, not a public A record. If the jumpbox is private but the agent subnet is not, fix PDZ links / DNS proxy / UDR before writing agent code.

Also confirm: Microsoft.App/environments delegation; public network access disabled on Foundry, Search, Storage, Cosmos; required RBAC; provider registration (Microsoft.App, Microsoft.Search, Microsoft.Network, and friends).

Capacity signals (portal does not expose delegated-subnet IP utilization cleanly): data proxy HTTP 5xx, Hosted agent session 4xx on create, new project provisioning failures. Plan a fresh instance + subnet rather than hoping.

Known Standard private-network constraints before you promise features: Code Interpreter file upload/download limits in BYO setups; Blob-backed File Search caveats; tool matrices in limits, quotas, and regions.

Pre-deploy checklist

Walk this list before capabilityHosts PUT:

  1. Agent subnet → Microsoft.App/environments, /24 for production (/27 only for known-small non-prod).
  2. Tools outside VNet vs tools-behind-VNet recorded (sample template 15 vs 19).
  3. APIM inbound PE on pe-subnet; outbound on dedicated Microsoft.Web/serverFarms subnet (/24 preferred).
  4. Seven privatelink zones exist once (hub); spokes resolve via firewall DNS proxy.
  5. Spoke DNS = firewall private IP; DNS proxy enabled.
  6. UDR 0.0.0.0/0 → firewall on every governed spoke subnet.
  7. Firewall rules: Foundry baseline + image/telemetry; agent (+ jumpbox) as sources.
  8. NSGs: agent/APIM → PE 443; APIM Storage/Key Vault; no public jumpbox.
  9. nslookup from jumpbox and agent path returns private IPs for Foundry, Cosmos, Storage, Search, APIM.
  10. BYO Storage, Search, Cosmos with PEs; public access off; project identity RBAC ready.
  11. Providers registered; Foundry account region matches VNet.
  12. IPAM non-overlap across peers; Class A confirmed if using 10.0.0.0/8.

Official samples under microsoft-foundry/foundry-samples infrastructure: 15-private-network-standard-agent-setup, 16-…-apim-setup, 19-…-agent-tools.

How this fits the stack (and this week)

Layer Role relative to BYO VNet
This playbook Landing zone, PE, DNS, firewall, irreversible subnets
Foundry AI Gateway / APIM Optional private front door on the same PE + outbound pattern
Toolboxes + user delegation Auth on connections; private MCP still needs PE DNS
Routines Unattended invoke on the secured endpoint—agent identity, not user OBO
Agent Framework harness Hosted images land in the network you already designed
Evals / Optimizer Trace egress often needs firewall allow-list entries

This week: run a 90-minute design review with platform + network + AI lead; reserve /24 agent and APIM outbound space in IPAM; file one firewall change for baseline FQDNs + MCR/ACR + monitor ingest; prove private DNS; only then create the first prompt agent and a PE-backed tool call. Document expected projects, hosted vs prompt mix, and concurrent sessions against the 80% utilization target.

Closing

Foundry Standard on a BYO VNet is not harder than other network-isolated Azure workloads. It is the intersection of Foundry, optional APIM, Cosmos, Search, and Storage—each with private-networking quirks. What makes it feel hard is deploying first and discovering constraints second.

Reverse the order: lock subnet layout and irreversible delegations, design Private DNS once in the hub, assemble firewall and NSG rules as a single network change, validate name resolution from the agent path, then run the template. Microsoft’s July 22 field guide and the Learn private-networking / networking deep-dive pages give you the canonical map. The checklist above is the deliverable your landing-zone ticket should attach.

Decide first. Deploy second. That is how Standard Agents earn the word production.

Sources

  1. Design the Network Before You Deploy: Best Practices for Microsoft Foundry Standard Agents BYOVNet — Microsoft Tech Community / Foundry Blog, Jul 22, 2026 (Priya Kedia).
  2. Set up private networking for Foundry Agent Service — Microsoft Learn.
  3. Deep dive into Foundry Agent Service networking — Microsoft Learn.
  4. How to configure network isolation for Microsoft Foundry — Microsoft Learn.
  5. Networking options for Foundry Agent Service — Microsoft Learn.
  6. Foundry samples — private network infrastructure (Bicep/Terraform) — official templates 15 / 16 / 19.
