Multi-Agent Orchestration Patterns in Microsoft Agent Framework: Concurrent, Sequential, Group Chat, Handoff, and Magentic

Microsoft Agent Framework reached another milestone this week with detailed guidance on five distinct orchestration patterns for multi-agent systems. The patterns—Concurrent, Sequential, Group Chat, Handoff, and Magentic—come with concrete code examples using the FoundryChatClient and the new builder APIs in agent_framework.orchestrations.

Paired with the recent general availability of declarative workflows (YAML-defined orchestration), these capabilities make it straightforward to move from prototype agents to governed, observable, production multi-agent applications inside Microsoft Foundry.

Why orchestration patterns matter

Single agents are useful for focused tasks. Real enterprise value appears when specialized agents collaborate on complex processes: one gathers context, another analyzes options, a third validates outputs, and a coordinator keeps the goal in view. Without explicit orchestration, teams end up with ad-hoc message passing, duplicated state logic, and fragile handoff code that is hard to review, test, or version.

The Microsoft Agent Framework provides a unified runtime and a set of builder classes so the same agent definitions can participate in different coordination styles. The patterns are not mutually exclusive; many production systems combine them. All of them run on top of Foundry resources with the same authentication, tracing, and evaluation surface you already use for single agents.

Core setup with FoundryChatClient

All examples in the new guidance start from a consistent foundation:

import os
import asyncio
from typing import cast
from agent_framework import Message, AgentResponseUpdate
from agent_framework.foundry import FoundryChatClient
from azure.identity import DefaultAzureCredential
from dotenv import load_dotenv

load_dotenv()

credential = DefaultAzureCredential()
chat_client = FoundryChatClient(
    credential=credential,
    project_endpoint=os.getenv("AZURE_AI_PROJECT_ENDPOINT"),
    model=os.getenv("AZURE_AI_MODEL_DEPLOYMENT_NAME"),
)

Use DefaultAzureCredential in production (works with Managed Identity). Store the project endpoint and deployment name in environment variables or Azure Key Vault. Agents are created with chat_client.as_agent(...) and carry instructions, descriptions, and options such as store=False for client-managed history when you need full control over conversation state.

The five orchestration patterns

1. Concurrent Orchestration

Multiple agents receive the identical input in parallel. Their independent responses are collected and returned together.

When to use:

• Different analytical perspectives are valuable (sentiment + category + priority).
• Voting or ensemble-style decisions.
• You want maximum parallelism for speed on independent subtasks.

Example (Ticket Assessment):

from agent_framework.orchestrations import ConcurrentBuilder

sentiment_agent = chat_client.as_agent(
    name="Sentiment Agent",
    instructions="You are a helpful assistant that analyzes the sentiment of a support ticket."
)
category_agent = chat_client.as_agent(
    name="Category Agent",
    instructions="You are a helpful assistant that categorizes a support ticket into categories such as Billing, Technical, Refund, or Account."
)
priority_agent = chat_client.as_agent(
    name="Priority Agent",
    instructions="You are a helpful assistant that determines the priority of a support ticket as High, Medium, or Low."
)

workflow = ConcurrentBuilder(
    participants=[sentiment_agent, category_agent, priority_agent]
).build()

result = await workflow.run("I was charged twice and I'm furious — refund me now!")
outputs = result.get_outputs()
for i, response in enumerate(outputs, 1):
    for msg in cast(list[Message], response.messages):
        name = msg.author_name or ("assistant" if msg.role == "assistant" else "user")
        print(f"{'-' * 60}\n{i:02d} [{name}]\n{msg.text}")

The builder handles fan-out and collection. You get structured outputs from each participant without writing custom asyncio gather logic.

2. Sequential Orchestration

Output of one agent becomes input to the next. Each stage can refine or transform the previous result.

When to use:

• Multi-step pipelines where order is fixed (summarize → classify → route).
• Iterative refinement loops (draft → review → improve).
• Processes that naturally build on prior context.

Example (Support Ticket Triage):

from agent_framework.orchestrations import SequentialBuilder

summarizer_agent = chat_client.as_agent(
    name="Summarizer Agent",
    description="Summarizes a support ticket into 1-2 sentences of core intent.",
    instructions="You are a helpful assistant that summarizes support tickets into concise summaries."
)
classifier_agent = chat_client.as_agent(
    name="Classifier Agent",
    description="Classifies a ticket summary into: Billing, Technical, Refund, or Urgent.",
    instructions="You are a helpful assistant that classifies a support ticket summary strictly into one of the following categories: Billing, Technical, Refund, or Urgent."
)

workflow = SequentialBuilder(
    participants=[summarizer_agent, classifier_agent],
    output_from="all"
).build()

ticket = "I was charged twice for my subscription this month and need a refund ASAP."
result = await workflow.run(ticket)
# Process outputs sequentially

output_from="all" ensures every stage’s messages are available downstream if needed. The framework manages the handoff of context automatically.

3. Group Chat Orchestration

A manager agent orchestrates a shared conversation among specialist agents. The manager selects the next speaker each turn and can request human input.

When to use:

• Cross-functional reviews or debates (product, engineering, design, security).
• Scenarios where the right next expert depends on what was just said.
• Human-in-the-loop governance points.

Key code pattern (abridged):

from agent_framework.orchestrations import GroupChatBuilder

# Define specialist agents + manager with instructions that enforce single-speaker selection and termination rules
workflow = GroupChatBuilder(
    participants=[product_agent, engineering_agent, design_agent, security_agent, manager_agent]
).build()

# Run and stream updates; manager decides flow

The manager’s instructions are critical: “Never select the same participant twice in a row. Once every perspective has been heard and a clear decision is reached, terminate the conversation with a short recommendation.”

4. Handoff Orchestration

Agents decide for themselves when and to whom to pass the conversation based on declared expertise. No central manager dictates the order.

When to use:

• Routing scenarios where the path is not known in advance.
• Dynamic customer support or troubleshooting flows.
• Situations where specialists need to escalate back to triage or other peers.

Example structure:

from agent_framework.orchestrations import HandoffBuilder

triage_agent = chat_client.as_agent(...)
refund_agent = chat_client.as_agent(...)
order_status_agent = chat_client.as_agent(...)

workflow = (
    HandoffBuilder(participants=[triage_agent, refund_agent, order_status_agent])
    .with_start_agent(triage_agent)
    .add_handoff(triage_agent, [refund_agent, order_status_agent])
    .add_handoff(refund_agent, [triage_agent])
    .add_handoff(order_status_agent, [triage_agent])
    .build()
)

# Interactive loop that accepts follow-up responses
responses = None
while True:
    if responses is not None:
        stream = workflow.run(responses=responses, stream=True)
    else:
        stream = workflow.run("Hi, I was charged twice for order #12345 and want a refund.", stream=True)
    # Process stream, collect new responses for next turn

require_per_service_call_history_persistence=True on agents ensures the framework maintains the right context across handoffs.

5. Magentic Orchestration

The most dynamic pattern. A dedicated manager agent maintains a task ledger and a progress ledger. It plans, assigns work, tracks what has been learned, replans on stalls, and synthesizes the final answer.

When to use:

• Open-ended or complex research and creation tasks.
• Problems where the exact sequence of steps cannot be known upfront.
• Autonomous multi-step projects that benefit from explicit planning and recovery.

Example (Autonomous Blog Drafting):

from agent_framework.orchestrations import MagenticBuilder

writer_agent = chat_client.as_agent(
    name="Writer Agent",
    instructions="You write clear, engaging blog posts on the requested topic."
)
editor_agent = chat_client.as_agent(
    name="Editor Agent",
    instructions="You review drafts for clarity and length, and suggest concise improvements."
)
manager_agent = chat_client.as_agent(
    name="Manager Agent",
    instructions="You coordinate the writer and editor to produce a polished final blog post."
)

workflow = MagenticBuilder(
    participants=[writer_agent, editor_agent],
    manager_agent=manager_agent,
    max_stall_count=2,
    max_round_count=10,
    intermediate_output_from="all"
).build()

stream = workflow.run(
    "Write a 300-word blog post explaining why sleep matters for productivity.",
    stream=True,
)

async for event in stream:
    if event.type in ("intermediate", "output") and isinstance(event.data, AgentResponseUpdate):
        # Print with executor labels
        ...
result = await stream.get_final_response()

The ledgers give the manager a persistent view of planned vs completed work, which is invaluable for observability and debugging long-running agent teams.

Comparison of the advanced patterns

Pattern	Control Model	Best For	Human-in-the-Loop	Deterministic Order
Group Chat	Manager picks next speaker	Debates, reviews, brainstorming	Yes (explicit)	No
Handoff	Agents route by expertise	Dynamic routing, support	Via instructions	No
Magentic	Manager maintains ledgers + replans	Open-ended research & creation	Via manager	No (planner driven)

Concurrent and Sequential are simpler building blocks you often embed inside the three more advanced patterns.

Getting started today

1. Provision a Microsoft Foundry resource and deploy a model (gpt-4.1-mini or stronger works well for orchestration).
2. Set AZURE_AI_PROJECT_ENDPOINT and AZURE_AI_MODEL_DEPLOYMENT_NAME.
3. Install the latest agent-framework package (the patterns are part of the 1.0+ surface).
4. Start with Concurrent or Sequential for your first workflow; they require the least orchestration code.
5. Add az monitor or Application Insights tracing to observe the full conversation graph.

The same agents you define for code-first workflows can participate in declarative YAML workflows. You can therefore version the high-level coordination in Git while keeping specialized agent instructions in code or in the Foundry project.

How this fits the broader Microsoft stack

These orchestration primitives sit alongside:

• Declarative workflows (YAML) for reviewability and governance.
• Foundry IQ for grounding agents in organizational knowledge.
• Copilot Studio for low-code composition and publishing to Microsoft 365.
• Agent 365 governance and evaluation tooling.

The result is a continuum: makers start in Copilot Studio, developers add custom orchestration in the Agent Framework on Foundry, and operations teams get unified observability and policy enforcement.

What to try this week

• Clone the example repository referenced in the August 5 guidance (https://github.com/SonakshiA/Multi-Agent-MAF) and run the five patterns against your own Foundry deployment.
• Take one of your existing single-agent prototypes and wrap it in a Concurrent or Handoff workflow to see the immediate lift in capability.
• Add a simple Group Chat review step to a content-generation pipeline and measure the quality improvement from specialist perspectives.

Microsoft continues to invest in making multi-agent systems first-class citizens of the Azure AI platform. The combination of stable orchestration builders, declarative definitions, and deep integration with the rest of the Microsoft 365 and Azure ecosystem gives teams a practical path from experimentation to production-grade agentic applications.

Sources

• “Exploring Multi-Agent Workflows with Microsoft Agent Framework”, Microsoft Foundry Blog, August 5, 2026. https://techcommunity.microsoft.com/blog/azure-ai-foundry-blog/exploring-multi-agent-workflows-with-microsoft-agent-framework/4542512
• “Orchestrate a multi-agent solution using the Microsoft Agent Framework” training module, Microsoft Learn. https://learn.microsoft.com/en-us/training/modules/orchestrate-semantic-kernel-multi-agent-solution/
• “Declarative Workflows 1.0 in Microsoft Agent Framework”, The Clearinghouse Log, August 5, 2026.
• Microsoft Foundry documentation and Azure AI Search / Copilot Studio integration notes (August 2026 updates).

All code examples adapted from the official guidance with minor formatting for readability. Always consult the latest SDK documentation and your organization’s security and compliance requirements before deploying to production.
