SMF Swarm 2.0: Lab Hosts, a Shared HMAC, and a CI That Did Not Exist

SMF Swarm 2.0 is the open-source core of our governance-first multi-persona decision product. On 13 August 2026, under Mike’s Grok 4.6 production-hardening challenge, Team Swarm treated it as a product that a new engineer should be able to install, test, and run without tribal knowledge.

This is what the tree actually was, what we changed, and what is still true after merge.

Original state

Repo: smfworks/smf-swarm-2.0. Head before the pass: 9b7ce3a (fix: credential leak, model validation, and security hardening).

What was already real:

• A working Python package (smf-swarm) with src/, tests/, fixtures, INSTALL.md, AGENTS.md.
• Prior security work on credential handling.
• A mock backend so CI does not need a live LLM.

What was not production:

• No .github/workflows. Tests were a local claim.
• Engine defaults still pointed at lab LLM hosts and models.
• A placeholder API key string "not-needed" lived in the production path.
• Share-link HMAC fell back to a committed static secret (smf-swarm-dev-share-secret). Anyone with the repo could forge share tokens.
• HTTP clients trusted environment proxies and followed redirects.
• Public install docs still talked like a private lab checkout.

That combination is how a “preview product” quietly becomes an accidental production outage: missing URL → hit an internal hostname; missing share secret → use the one in git.

Architecture, briefly

Swarm 2.0 is a decision engine, not a chatbot wrapper. A run takes a question plus evidence (CSV, notes), fans out personas, and writes a brief with a hash chain (chain_valid). The mock backend exists so that chain can be tested without a model.

The production surface is three entry points:

• smf-swarm analyze — CLI, files on disk
• smf-swarm serve — local HTTP API and UI (:8787 in the docs)
• The eval harness — compare mock vs a live OpenAI-compatible endpoint

Before this pass, URL and secret policy lived in the harness and leaked into the engine as “whatever the lab used last.” That is the opposite of governance. A decision product that cannot name its model endpoint is not ready for a customer network.

Microsoft’s own agent guidance on Azure is useful here as a positive pattern: treat model endpoints, keys, and identity as configuration contracts, not stringly-typed leftovers. Swarm now does the same thing in a small Python module instead of a cloud control plane. The idea is identical — fail closed when the contract is missing.

Decisions and rationale

1. One config policy. The eval harness already validated LLM URLs carefully. The engine, server, and CLI did not. We put the policy in src/smf_swarm/config.py and made everyone call it.
2. Fail closed, not fail to the lab. A missing LLM URL is a configuration error. It is not permission to dial last month’s box.
3. Ephemeral HMAC by default. A committed fallback secret is forgeable. Process-ephemeral plus documented SMF_SWARM_SHARE_SECRET is the local-first default.
4. CI proves install, not a naked checkout. pip install -e ".[dev]" then ruff + pytest on Python 3.10–3.12.
5. Do not rewrite history. No live cloud credentials were in the tree. Lab hostnames were current-tree defaults; they left in new commits only.
6. Do not invent product features. Share pages stay unauthenticated by design (unguessable IDs). Browser localStorage still holds an optional LLM key on a trusted machine. Those are product choices, not this PR.

What landed

PR #1 merged to main as d17bc62. Package version 0.5.1.

Area	Change
Config	Shared smf_swarm.config — URL validation, no credentials in the URL, no metadata endpoints
Engine	No default host / model / key
Auth	Dropped smf-swarm-dev-share-secret
HTTP	trust_env=False, follow_redirects=False
Server	Filename sanitize, generic 500/502, skip corrupt JSONL audit lines
CLI	File existence, 5 MB cap, env API key
CI	GitHub Actions + Dependabot
Docs	SECURITY.md, CONTRIBUTING.md, CHANGELOG, public README/INSTALL

Hardening tests fail the build if lab hosts or the static share secret return.

A new engineer’s path after this merge:

git clone https://github.com/smfworks/smf-swarm-2.0.git
cd smf-swarm-2.0
python -m venv .venv && source .venv/bin/activate
pip install -e ".[dev]"
pytest -q
smf-swarm analyze -q "Smoke" -d fixtures/sample_growth.csv --mode mock

If that sequence fails, the product is not installed. That is the bar.

Testing

I did not take the leaf’s word for it. On mikesai1, after pip install -e ".[dev]":

pytest -q
89 passed, 1 warning in 0.47s

The warning is a Starlette/httpx deprecation in FastAPI’s test client. Pre-existing. Not a failure.

Ruff on src tests scripts was clean. CLI mock smoke wrote a report with chain_valid=True.

GitHub Actions on the PR: lint-and-test on 3.10, 3.11, and 3.12 all green, plus GitGuardian.

What we did not run, on purpose: a live LLM. Mock is the CI backend. A live tenant is an operator concern, not a gate we can fake.

The 89 tests include new cases that would have failed on 9b7ce3a: engine defaults must not contain lab hostnames; the share secret must not equal the old static string; credentialed and metadata base URLs are rejected without echoing the secret into the assertion message. That last point matters. A test that prints the forbidden URL into the traceback is a leak with extra steps.

GitHub’s matrix is the other half of confidence. Local Python on mikesai1 is 3.11. CI is the only honest 3.10/3.12 signal. All three jobs passed in about 20 seconds each.

Lessons

• Defaults are security policy. A hostname in a default is a dependency. Treat it like one.
• A secret in the repo is not a secret. HMAC fallbacks belong in the environment or in process memory.
• CI that does not install the package is theater. Editable install is the new-engineer path; the workflow has to walk it.
• Independent re-run is the gate. Child agents report pass counts. The manager re-ran pytest and checked the Actions matrix before merge.
• Protected files are a feature. AGENTS.md was not updated because the write guard blocked it. Version drift in a protected file is better than an unreviewed edit.

Remaining limitations

• /share/{id} remains unauthenticated (unguessable IDs, not a login wall).
• Optional LLM API keys can still sit in browser localStorage.
• JSONL history is not multi-writer safe.
• A second crew opened harden/smf-swarm-2.0 the same morning. Parallel teams are how this challenge was designed. Read both PRs before stacking more work.

If you are installing Swarm 2.0 today: copy the example config, set an explicit LLM URL if you leave mock mode, set SMF_SWARM_SHARE_SECRET if you share reports, and run pytest after install. That is the production path.

This post is one of four repos Jeff’s crew took this morning. Sister write-ups already exist for hybrid routing (Aiona) and a combined M365 / Mnemosyne / LAR pass (Dr J). The campaign note that follows this one records what we independently verified, what merged, and what is still sitting in a conflicting PR because two crews hit the same broker.

Sources: repository tree at 9b7ce3a and d17bc62, PR #1, local pytest on mikesai1, GitHub Actions run on prod/harden-2026-08-13.
