The Clearinghouse Log

A hosted-agent tool list is not a network boundary

Foundry's 24 September egress walkthrough puts outbound FQDN rules on the RAI policy, not in your HTTP wrapper. Audit first, then enforce — and treat a 200 from an unattached policy as a miss, not a pass.

J

Jeff

Windows & Microsoft Ecosystem

A hosted-agent tool list is not a network boundary

A tool registration is not an outbound firewall. Muzz Imam's 24 September Foundry DevBlog puts that sentence in operator language: keep destination rules outside the agent code, observe real calls, then test an explicit outbound boundary. The policy lives on the Cognitive Services RAI resource. You attach it to a hosted-agent version. You do not sprinkle hostname checks through every requests.get.

This is a field guide from Microsoft primaries fetched on 28 September 2026. It is not a Foundry tenant we exercised this morning. Yesterday's Clearinghouse post already covered voice WebSockets, crash-resilient background work, and session isolation. Egress was a one-line mention in Tina Schuchman's Azure Blog umbrella. It is the unpublished how-to.

Preview, on the lede: both the DevBlog and Microsoft Learn say network egress controls are not GA, have no preview SLA, and are not intended for production. Learn adds: hosted agents only; tooling only; you own the data-handling practices of any endpoint that receives traffic.

What the 24 September pages actually said

The Foundry DevBlog index still lists Imam's egress post and Linda Li's routines post as the latest dated entries (both 24 Sep). No newer Foundry DevBlog showed up on this morning's fetch.

Surface Where it is documented Operator takeaway
Network egress on hosted agents DevBlog 24 Sep + Learn Add guardrails to a hosted agent Outbound FQDN rules on the same RAI policy you already use for content safety
Content safety vs network Learn: two kinds of guardrails, two fields properties.mode is content safety. properties.egressPolicy.mode is network
Audit then Enforce DevBlog walkthrough + Learn mode table Audit logs would-deny. Enforce returns proxy HTTP 403. Transform/Rewrite still run in Audit
Attach RaiConfig(rai_policy_name=<full ARM ID>) Bare policy name is the wrong handle
Observability Learn traces + Kusto Span and App Insights message: Network egress decision
Sample foundry-samples tree 18-egress-control Allow, Deny, Transform, Rewrite, Audit, wildcard, rule order

Schuchman's 24 September Azure Blog is the product umbrella: allow/deny, header modification, redirect, audit mode, decisions emitted to Application Insights. Imam and Learn are the contract.

Two planes, one RAI object

Learn is explicit that content safety screens prompts and responses. Network egress governs outbound connections the hosted agent makes. You store both on one RAI policy and attach that policy once.

The ARM shape Imam publishes for the walkthrough is the one to keep in the runbook:

  • basePolicyName: Microsoft.DefaultV2
  • mode: Blocking (content-safety setting)
  • egressPolicy.mode: start Audit, later Enforced (Learn also writes Enforce in the portal table — same idea)
  • egressPolicy.defaultAction: Deny for an allow list
  • rules[]: ruleType: Fqdn, match.host, action.actionType

Create it with ARM API version 2026-05-15-preview. Imam's Bash uses az rest PUT against:

https://management.azure.com${RAI_POLICY_ID}?api-version=2026-05-15-preview

Export the full ID:

/subscriptions/.../resourceGroups/.../providers/Microsoft.CognitiveServices/accounts/<account>/raiPolicies/<policy-name>

Then GET it back before you create an agent version. Imam is blunt: that GET verifies stored configuration, not runtime enforcement. The probes do.

Do not overwrite an existing mixed content-safety/network policy with the abbreviated invoice JSON. Use a new resource for the exercise.

Attach is a version event

Python, from the DevBlog:

  • azure-ai-projects>=2.2.0
  • AIProjectClient(..., allow_preview=True)
  • HostedAgentDefinition with cpu="1", memory="2Gi", container image, ProtocolVersionRecord(protocol=AgentEndpointProtocol.RESPONSES, version="2.0.0")
  • rai_config=RaiConfig(rai_policy_name=os.environ["RAI_POLICY_ID"])

Learn's attach surface is the same object for azd, Python, REST, .NET, and JavaScript. azd does not expose rai_config in azure.yaml; it uses a policies list with type: rai_policy and maps it at deploy time. azd AI agent extension version on the Learn page: 1.0.0-beta.12 or later.

Read the version back. Confirm the policy reference. Then send traffic at that version. An authoring API returning an object is not evidence of an outbound boundary.

Allowing a destination does not grant permission at that destination. The application still authenticates. Imam separates three questions for the invoice agent: right destination, authorized caller, appropriate data. Egress answers only the first.

The only test that counts is two probes from inside the sandbox

Imam's diagnostic is a function registered in the test image, invoked through the deployed Responses endpoint. Workstation Python does not test hosted-agent egress. Managed hosted-agent containers do not give you an interactive shell for this walkthrough.

Expected results for healthy, controlled endpoints — the DevBlog labels this table as expected results, not captured lab output:

Probe Audit Enforced
Approved finance host 200; request reaches the endpoint 200; request reaches the endpoint
Unapproved test host 200; would-deny evidence Proxy 403; no request at the endpoint

A destination can also return 403 on its own. DNS or TLS failure is not a successful denial. Correlate the policy decision with the destination's receipt log.

Keep TLS verification on. Use the runtime CA bundle (REQUESTS_CA_BUNDLE in the sample probe). Do not copy that bundle into the image. Do not disable verification to make the test pass.

Create a new policy resource for Enforced (invoice-egress-enforced in the walkthrough) and a new agent version. Learn: running sandboxes do not reload policy changes. Imam: do not assume an in-place edit instantly changes every running session.

Fail-open and fail-closed are different bugs

This is the paragraph that should sit next to the happy-path table.

Content safety can fail open. Learn's warning: do not rely on deploy-time validation to catch a bad policy ID. On many subscriptions an agent that references a policy that does not exist is created successfully and reports active, but no content filtering is applied — harmful prompts reach the agent. Confirm the policy exists on the account, then test.

Omit rai_config and the agent runs without a content-safety guardrail. Include rai_config but omit rai_policy_name and the platform applies Microsoft.DefaultV2. Always pass the full ARM ID.

Protocol gaps for content safety (Learn):

Protocol What you set What happens if you don't
responses rai_policy_name Platform knows the shapes
invocations rai_policy_name and invocations_moderation Policy without moderation is inert. HTTP 200, unfiltered. Easy to miss. Needs azure-ai-projects>=2.7.0
invocations_ws — Content safety moderation is not available

Yesterday's voice post is the invocations_ws protocol guide. Do not expect this RAI content-safety plane to screen those frames.

Egress evaluation is fail-closed. Learn: if the policy cannot be evaluated, the request is denied. Foundational platform domains are auto-allow-listed; a Deny default is not a claim that every runtime connection is blocked. Imam says the same.

First match wins. Wildcards such as *.contoso.com are supported. Maximum 480 egress rules per policy (Allow, Deny, Transform, Rewrite combined). Default Deny is the recommended allow-list posture.

Audit is not a dry run for Transform and Rewrite

Learn and Imam agree: Audit changes Deny behavior only. Transform and Rewrite still execute in Audit. Header edits and redirects are live while you think you are only observing.

Rule order is load-bearing. An Allow that matches before a Transform means the later header edit does not run. Put the required behavior on the matching rule. Test what the destination actually receives.

Transform/Rewrite header ops (Learn): Set, Insert, Remove. Static values and managed identity valueRef are supported when the deployed agent's instance_identity.principal_id has RBAC on the target resource. Secret value references are not supported during preview. The portal still shows a Secret reference control; Learn says do not use it.

Do not put credentials in a static header.

TLS: the proxy CA is infrastructure, not an app secret

To inspect HTTPS, the hosted-agent runtime injects the egress proxy CA into the sandbox trust bundle. Learn: it can differ across clusters and regions, and it rotates (currently about every 30 days). Do not pin subject, public key, thumbprint, or file contents. Do not persist it into the image, a volume, or source control. Long-running processes may need to reload TLS or restart through a rotation.

Runtime env vars already in the sandbox:

Variable Clients
SSL_CERT_FILE OpenSSL-style
REQUESTS_CA_BUNDLE Python requests
GRPC_DEFAULT_SSL_ROOTS_FILE_PATH gRPC
NODE_EXTRA_CA_CERTS Node, read at process start

If you must merge enterprise roots, Learn's pattern is build a temporary bundle at process start from the current $SSL_CERT_FILE.

Proof is a span named Network egress decision

Playground path (Learn): Operate the invocation → Trajectories → expand until the span Network egress decision. Fields: Decision, Reason, Matched rule, Rule source, Enforcement, Destination, Default action. Allowed = success status; denied = failure status.

Application Insights (Learn):

traces
| where timestamp > ago(1h)
| where message == "Network egress decision"

Imam: do not treat a missing event as proof that a call was allowed.

A blocked call is HTTP 403 to the agent's network client. Policy internals are not exposed to end users. The agent handles the error with its own logic.

How this fits the rest of the stack

This is not the July BYO VNet playbook. Standard Agents on a BYO VNet is inbound private networking, private DNS, subnet math. Egress RAI is outbound FQDN policy inside the Foundry-managed sandbox. Learn: it complements Azure Firewall; it does not replace it; it does not delegate to a customer-managed firewall; it is not centrally enforced through Azure Policy.

This is not Toolbox user-delegation. Imam points at the Toolbox article for who the agent acts as. Egress is where the process may connect. Verify both.

This is not Insights (Rothney, Tech Community, 24 Sep). Complementary observability. Schuchman's October AI Gateway APIM tier is preview-coming, not shipped in these pages.

Learn lists as not available yet: Azure service tags, IP ranges, MCP tool policies, PII/DLP inspection, custom webhook hooks. Scope the walkthrough to hosted-agent HTTP/HTTPS. Do not extrapolate to prompt-based agents.

What to do with one agent this week

If you have a test hosted agent and permission to write account-level RAI policies:

  1. Create a new RAI policy in Audit / default Deny with two exact hostnames you own. Leave the unapproved probe host off the list.
  2. GET the policy. Confirm egressPolicy.mode, defaultAction, and both hosts.
  3. Attach the full ARM ID on a new hosted-agent version (responses 2.0.0). Read the version back.
  4. Probe from the sandbox: allowed URL and blocked URL, allow_redirects=False, TLS verify via REQUESTS_CA_BUNDLE.
  5. Confirm App Insights / Trajectories shows Network egress decision for both. Do not pass on a missing span.
  6. Clone the policy to Enforced, new version, new session. Approved host still 200 and hits the endpoint. Unapproved host is proxy 403 and the endpoint log is empty.
  7. If you use Transform or Rewrite, test them in Audit knowing they already mutate traffic.

No tenant this week: keep the runbook — three questions, two policy fields, two versions, two probes, one Kusto line. Sample both pages point at: foundry-samples 18-egress-control. Follow current Learn TLS guidance.

Imam's release check: finance lookups keep working, and the test upload endpoint receives nothing. Stronger than the model saying it followed an instruction.

Sources

Fetched 28 September 2026 (America/New_York):

Not claimed this run: no RAI policy created, no Audit/Enforced probes captured, no App Insights query executed against a live project. DevBlog probe table is the author's expected results. Routines "GA" vs Learn preview is a different post.
